• 3.55 axle ratio
• Rear wheel drive
• 58 amp-hour (540 CCA) maintenance-free battery w/battery-saver feature
• 130 amp alternator
• 4-pin trailer tow wiring
• 6-1/2' pickup box w/tie-down hooks
• 6000# GVWR/1930# maximum payload
• 3400# capacity twin forged SLA front axle
• 3800# capacity rear axle
• 2650# capacity front coil/3200# capacity rear leaf springs
• Gas-pressurized shock absorbers
• P255/70R16SL all-season SBR OWL tires
• P235/70R16SL all-season SBR BSW spare tire
• 16" x 7.0" 5-hole 6-spoke cast-aluminum wheels w/chrome hubs
• Pwr steering
• Pwr front disc/rear drum brakes
• Four-wheel anti-lock brake system
• 25.0 gallon fuel tank

• Chrome front bumper
• Chrome rear step bumper w/5000# tow rating
• Color-keyed wheel opening moldings
• Color-keyed grille/headlamp surround
• Color-keyed body-side moldings
• Bed-rail/tailgate moldings
• Cargo box light
• Dual pwr signal mirrors w/color-keyed caps
• Rear quarter window flip-out glass
• Quarter/side window privacy glass
• Speed-dependent interval wipers
• Color-keyed door handles
• Third door rear access for passengers/cargo
• Removable locking tailgate w/black handle

• Leather split bench seat w/recliners/armrest/driver-side manual lumbar adjustment
• Vinyl split bench rear seat
• Color-keyed carpeting w/floor mats
• Color-keyed leather-wrapped steering wheel
• Voltmeter, oil pressure/temp/speedomter/fuel gauges
• Tachometer
• Pwr windows w/driver side one-touch down/delayed accessory pwr
• Pwr door locks
• Electronic AM/FM stereo radio w/4 speakers, digital clock
• Dual instrument-panel-mounted cupholders
• Auxiliary pwr point
• Vinyl upper/carpeted lower door trim w/integral armrest, map pocket, grab handle
• Headliner
• Cloth sun visors w/LH strap, RH mirror
• Dome light w/dual map lights
• Underhood light

• Driver & front passenger air bags w/passenger-side deactivation switch
• Seat belts w/LH adjustable shoulder
• Four-wheel anti-lock brake system
• Side door intrusion beams (1997)

4.6L EFI OHC V8 "TRITON" ENGINE

• (STD)

• Rear Wheel Drive
• Aluminum Wheels
• Power Steering
• Front Disc/Rear Drum Brakes
• Power Mirror(s)
• Integrated Turn Signal Mirrors
• Privacy Glass
• Intermittent Wipers
• Third Passenger Door
• Leather Seats
• Driver Adjustable Lumbar
• Rear Bench Seat
• Floor Mats
• Leather Steering Wheel
• Power Windows
• Power Door Locks
• AM/FM Stereo
• Power Outlet
• Front Reading Lamps
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag On/Off Switch

• Mileage
• EPA Fuel Economy Est - City (MPG): 16
• EPA Fuel Economy Est - Hwy (MPG): 19
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 540
• Maximum Alternator Capacity (amps): 95
• Maximum Alternator Watts: 1425
• Cooling System
• Total Cooling System Capacity (qts): 17.9
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 2650
• Gross Axle Wt Rating - Rear (lbs): 3200
• Curb Weight - Front (lbs): 2354
• Curb Weight - Rear (lbs): 1691
• Gross Vehicle Weight Rating Cap (lbs): 6000
• Gross Combined Wt Rating (lbs): 7,800
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 2,000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 200
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 2,000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 300
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 2,000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 500
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 2650
• Spring Capacity - Rear (lbs): 3200
• Axle Type - Front: Twin Forged SLA
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3400
• Axle Capacity - Rear (lbs): 3800
• Axle Ratio (:1) - Rear: 3.55
• Shock Absorber Diameter - Front (mm): 30.2
• Shock Absorber Diameter - Rear (mm): 30.2
• Stabilizer Bar Diameter - Front (in): 1.18
• Brakes
• Brake Type: Power
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.13 x - TBD -
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 11.03 x 2.25
• Tires
• Front Tire Order Code: T55
• Rear Tire Order Code: T55
• Spare Tire Order Code: T55
• Front Tire Size: P255/70R16SL
• Rear Tire Size: P255/70R16SL
• Spare Tire Size: P255/70R16SL
• Front Tire Capacity (lbs): 2064
• Rear Tire Capacity (lbs): 2064
• Spare Tire Capacity (lbs): 2064
• Revolutions/Mile @ 45 mph - Front: 695
• Revolutions/Mile @ 45 mph - Rear: 695
• Revolutions/Mile @ 45 mph - Spare: 695
• Wheels
• Front Wheel Size (in): 16.0 x 7.0
• Rear Wheel Size (in): 16.0 x 7.0
• Spare Wheel Size (in): 16.0 x 7.0
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 14
• Turning Diameter - Curb to Curb (ft): 45.92
• Turning Diameter - Wall to Wall (ft): 47.66
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 25.0
• Fuel Tank Location: Midship
• Exterior Dimensions
• Wheelbase (in): 138.5
• Length, Overall w/o rear bumper (in): 220.8
• Width, Max w/o mirrors (in): 78.4
• Height, Overall (in): 72.8
• Overhang, Front (in): 37.2
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): - TBD -
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 32.3
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): - TBD -
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.8
• Cargo Box Width @ Top, Rear (in): 62.1 @ Belt
• Cargo Box Width @ Floor (in): 60.3
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.7
• Tailgate Width (in): 65.2
• Cargo Volume (ft³): 58.6
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 40.8
• Front Leg Room (in): 40.9
• Front Shoulder Room (in): 63.8
• Front Hip Room (in): 61.3
• Second Head Room (in): 37.8
• Second Leg Room (in): 32.2
• Second Shoulder Room (in): 64.7
• Second Hip Room (in): 64.9
• Summary
• Vehicle Name: Ford F-150
• Body Style: Supercab 6.5' Styleside
• Body Code: 138.5" WB
